SUP23T Fiber Laser Handheld Welding Head 4 in 1

SUP23T

The SUP23T Four-in-One Handheld Welding Head is designed for laser welding, non-contact cleaning, seam cleaning, and cutting. It features a handheld laser head and a control system with enhanced safety functions. Building upon the SUP20T, the SUP23T is more compact, lighter, and more reliable, with improved insulation, stability, and ease of maintenance. It supports various fiber lasers and is optimized for cooling, ensuring stable operation at power levels up to 3000W. In cleaning mode, it can achieve a maximum cleaning width of 120mm.

Product Features

  • Perfectly Safe: Independent research and development of security detection system, set up a number of security alarms, security and stability.

  • Efficient and Convenient: Equipped with a focus lens and protective lens drawer for easy replacement. The collimating lens is integrated with the QBH interface, allowing for quick and convenient changes.

  • Compact and Easy to Use: Smaller size, lighter weight, and flexible operation make it more comfortable and user-friendly.

  • Excellent Welding, Stable Performance: Optimized optical structure provides high welding strength, minimal deformation, and deep penetration for superior welding quality.

  • Versatile Functions: Supports handheld continuous welding, spot welding, cleaning, cutting, and seam cleaning. Manual and automatic integration with password authorization. Real-time interface monitoring ensures easy on-site maintenance and enables remote technical support.

Technical Data

Model SUP23T
Input Voltage 220V ±10% AC 50/60Hz
Installation Environment Flat, no vibration and impact
Working Environment Temperature 10~40 ℃
Working Environment Humidity ＜ 70%
Cooling-down Method Hydrocooling
Applicable Wavelength 1064nm (±10nm )
Applicable Power ≤3000W
Alignment D16/F60
Focus D20/F150
Maximum Air Pressure 15Bar
Focus Vertical Adjustment Range ±10mm
Scan Width – Weld 0~8mm
Net Weight 0.75kg

Product Structure

Product Dimensions
